Parameter Item
|
Specification Description
|
|
Main Control SOC
|
RK 1103BG2
|
|
Sensor
|
SC200AI
|
|
GPS Module
|
Single-band
|
|
Lens Parameters
|
– Horizontal Viewing Angle: 144° – Vertical Viewing Angle: 82.5° – Resolution: 2K – Focal Length: 2.8mm
|
|
Battery Capacity
|
1100mAh
|
|
4G Module
|
Yuge VSIM
|
|
WIFI Module
|
H161
|
|
Electric Shock
|
No
|
|
2.0
|
|
|
Video Compression Standard
|
H.265/15FPS
|
|
Video Format
|
MP4
|
|
Vibration
|
Yes
|
|
Network Access
|
WIFI/4G
|
|
Network Connection
|
Global Wifi/4G network, supports Bluetooth quick connection
|
|
Audio
|
Built-in microphone and speaker, supports two-way intercom & custom alarm voice; adopts ADPCM audio compression standard with adaptive stream rate
|
|
Alarm Function
|
① Motion detection with picture push notification ② Remote active wake-up via APP
|
|
Storage
|
Built-in TF card slot (FAT32 format, maximum support 256G)
|
|
Fast Charging
|
Not supported
|
|
Behavior Recognition
|
Only supports “Walking” and “Running”
|
|
Electronic Fence
|
Supports 2 fences (timed switch available)
|
|
Night Vision
|
Not supported
|
|
Image Stabilization
|
Not supported for SD card storage; supported on APP side
|
|
Modes
|
Away Mode / Training Mode (set via APP); Away Mode: only triggers alarm recording actively (including cross-border alarm recording, beacon trigger recording, bark wake-up recording); Training Mode: 24-hour continuous recording (high power consumption)
|
|
Lost Mode
|
Supports pet lost mode setting in APP (scan the device QR code and fill in pet information. When the pet is lost, enable lost mode in APP, others can scan the QR code to contact the owner)
|
|
APP Push Notification
|
1. Access entry/exit push (video + photo + notification) 2. Forbidden beacon area access push (video + photo + notification) 3. Cross-border push (video + photo + notification) 4. Low battery push 5. Custom mood & posture trigger push 6. Manual power on/off push 7. Email cross-border map marking push
|
|
Beacon
|
Supported; up to 5 beacons; not included in the quotation, optional for customers.1. Access entry/exit recognition2. Place in forbidden areas to prevent pets from approaching and damaging valuables
|
|
Size & Weight
|
Device: 7.2*4.5*3CM, 100g; Collar diameter: 8-20CM
|
